Holley EFI Terminator X Fuel Injector 100 lbs/hr USCAR Plug EV6 Body 522-101X
(Prior to Dispatch)
| Brand |
 |
|---|---|
| GTIN | 90127127261 |
| MPN | 522-101X |
| Handling Time | 7-10 Business Days |
| Return Policy | No Return (Unless Manufacturer Defect) |
| Warranty | Manufacturer Warranty |
| OEM Replacement | No |
| Injector Advertised Flow Rate (lbs./hr.) | 100 lbs./hr. |
| Injector Advertised Flow Rate (cc/min.) | 1,050.0cc/min. |
| Injector Plug Style | USCAR |
| Injector Body Style | EV6/Pico |
| Injector Impedance | 12.2 ohms |
| Driver Type | 12V saturated circuit |
| Overall Height (in.) | 1.85 in. |
| Seat to Seat Height (in.) | 1.421 in. |
| Outside Diameter (in.) | 0.650 in. |
| Wiring Harness Included | No |
| O-Rings Included | Yes |
| Remanufactured | No |
| Quantity | Sold individually. |
| Notes | High-impedance injectors. |
| Special Attention | Compatible with many LSA, LS3, LS7, L76, L92, L98, L99, LS9 OEM LS intake manifolds. |
Holley EFI Terminator X Fuel Injector 100 lbs/hr USCAR Plug EV6 Body
Holley EFI Terminator X fuel injectors feature a precision lapped disc valve, high-quality brass windings, and high-temperature O-rings. These injectors provide excellent linearity with no discernible "bounce" at low pulse widths as commonly found in other injectors. With a wide variety of fuel flow offerings from 42 lb./hr. to 220 lb./hr. you are sure to find an injector that matches your non-emissions-controlled application. Holley EFI Terminator X fuel injectors can also be used with any ECU that utilize high-impedance fuel injector drivers. Features: * PICO/EV6-style performance injectors are sold individually or in a set of 8 * High impedance for use with saturated drivers * Rated injector flow 220 lb./hr. at 43 psi of base fuel pressure * USCAR injector connector * 40mm O-ring to O-ring length * Compatible with many OEM LS intake manifolds * Easy to install in any Holley EFI Hi-Ram intake, using Holley fuel rail adapter kit
