For copper single conductors up to 16 mm, multiple stranded wires up to 50 mm, fine stranded up to 70 mm and aluminium conductors multiple stranded wires up to 70 mm
Easy cutting with one-hand operation due to high transmission ratio
Stainless - special grade - steel, oil-hardened and tempered
Not suitable for steel wire and hard drawn copper conductors
Precision-ground, hardened blades
No crushing, slight deformation of the cable only
Adjustable bolted joint
Specifications
Article No.: 95 06 230
EAN: 4003773006305
Head: polished
Handles: plastic insulated, VDE-tested
Weight: 274 g
Dimensions: 230 x 82 x 30 mm
Standard: DIN EN 60900 IEC 60900
REACH compliant: does not contain SVHC
RoHS compliant: not applicable
Cutting capacity copper cable, multiple-stranded: 50 mm
Cutting capacity copper cable, multiple-stranded: 16 mm
