Kukko Counter Stay Clamping Depth 115mm
OverviewCounter stays from the 22 series are used together with internal extractors from the 21 series in trade, industry and workshops. Counter stays are particularly suitable for large cylinder liners and ball bearings etc. thanks to the ribbed shape of the support feet and ensure a firm stand when extracting. This improves the gentle extraction of internal parts.
ApplicationTogether with internal extractors of the series 21
Sizes from 21-2 are particularly low-friction due to thrust bearings integrated in the mould
The frictional resistance of the counter stay nut is minimised by a built-in thrust bearing
Total width: 105mm
Total depth: 33mm
New weight: 0.69kg
Width across flats: 22mm
Thread length: 150mm
Material: Tool steel
Clamping depth: 115mm
External thread of the spindle (nominal dimension): M15x1.5
Internal thread of the spindle (nominal dimension): M7, M10
Span of counter support (min-max): (9787) -(9788)
Counter support span (min): 15mm
Counter support span (max): 60mm
Clamping depth of counter support: 115mm
