Kukko Steering Wheel Puller 34-1

Kukko Steering Wheel Puller

The 2-armed steering wheel puller is used to pull off steering wheels with large puller slots. The 34-0 model is equipped with a pair of short puller legs. The 34-1 model has an additional pair of long puller legs. Due to their design, the legs can be adjusted in any direction. Thanks to the sturdy design of the puller, it is possible to reach into large puller slots to reach the steering wheel.

• For removing steering wheels with large removal slots

• Anti-slip guard on the spindle head for safe working with wrench

• Spindle riser protects the threading

• Separate protective cap for the steering column thread is included

• Total width: 105mm

• Total depth: 25mm

• Total height: 155mm

• Net weight: 0.96kg

• Width across flats: 17mm

• Span outside pull-off (min): 28mm

• Span outside pull-off (max): 90mm

• Clamping depth outside pull-off: 85mm

• Hook root thickness at the tip (claw thickness): 5mm

• Hook base width (claw width): 8mm

• Hook base depth usable (claw depth usable): 3.5mm

• Total hook root depth (total claw depth): 11.5mm

• Total claw thickness (claw distance to base surface): 5mm

• Material: Tool steel

• Scale division: No
