Tempo Communications Optical Power Meter OPM
Tempo Communications Netcat Pro 2 Kit
Tempo Communications Micro Optical Power Meter OPM210
MPN: OPM210
|
RPI: 3269388
or 4 interest-free payments of
$25,000.00
Trackable Shipping
Australia Wide
Handling Time
7-10 Business Days Handling Time(Prior to Dispatch)
Return Policy
No Return (Unless Manufacturer Defect)
Type in your postcode or suburb to get an estimate on postage cost.
Estimate
Save more when you buy more with combined postage
Click & Collect (no postage cost)
Unit 1/25 Bearing Road, Seven Hills, NSW, 2147
Ready-to-pickup: 7-10 Business Days *
* You'll receive a notification when your order is ready for pickup. For store details and opening hours, click
here
Brand
MPN
OPM210
Handling Time
7-10 Business Days
Return Policy
No Return (Unless Manufacturer Defect)
Warranty
Manufacturer Warranty
Tempo Communications Micro Optical Power Meter Overview
The Tempo Communications Micro Optical Power Meters (OPM210 and OPM220) are available in standard and high-power versions for the Telco and MSO markets. Absolute and referenced power measurements ensure fast and accurate loss budget and insertion loss measurements. When placing tones on the fiber using a Tempo Communications source provides the optical power meter will definitively identify fiber optic cables.
Features
Standard and High Power Optical Power Meters
Measure Optical Power (dB, dBm & mW)
Accurate Insertion Loss Measurements
Tone and Probe Fiber Networks at 270Hz, 1kHz and 2kHz
Absolute or Referenced Optical Power Measurements
Integrated Visual Fault Locator
Integrated Flash Light
InGaAs detector for Maximum Sensitivity
Calibrated Wavelengths 850nm, 1300nm, 1310nm, 1490nm, 1550nm & 1625nm
Universal Bulkheads
Compatible with Singlemode and Multimode Networks
Auto Off or Continuous On Operation
AA Battery Operation
Specifications
Measuring Range OPM210: -70 to + 10dBm (1310/1490/1550/1625); -60 to +10dBm (850/1300) Measuring Range OPM220: -50 to +26dBm (1310/1490/1550/1625); -40 to +26dBm (850/1300) Calibrated Wavelengths 850, 1300, 1310, 1490, 1550, 1625nm Display Resolution 0.01dB Connector Universal 2.5mm Accuracy +/-0.25dB Linearity OPM210: +/-0.5dB (+10 to -3dBm); +/-0.1dB (-3 to -50dBm); +/-0.5dB (-50 to -70dBm) / OPM220: +/-0.5dB +26 to -3dBm; +/-0.1dB -3 to -50dBm Wavelength Response 700 - 1700nm Detector Type InGaAs Power Supply AAA x 2 Alkaline Battery Life >60 Hours (OPM mode) Operating Temperature -10 to +50C (
